LGB-5 CSD - 1 Common Parts Drawing
Index
Part No.
511-246-290 Manual Gas Valve, 1" N.P.T
511-246-325 Main Shut-Off Gas Valve, 1" N.P.T. with 2 ⅛" taps
511-246-339 Leak Test Valve
511-044-039 Pilot Line Solenoid Gas Valve, ¼" N.P.T., 24 Volt
510-933-195 Pilot Line Gas Pressure Regulating Valve, 3.5-7.0" W.C. Outlet Adjustment Range, ¼" N.P.T. Pilot Gas Shut Off Valve, ¾"
511-246-345 Pilot Line Manual Shut-Off Gas Valve, ¼" N.P.T. Male x ¼" N.P.T. Female Pilot Tubing, Aluminum, ¼" x 20", 2 Pieces Required
560-742-880 Pilot Line Aluminum Tubing, ¼" Dia. X 20" Long
510-933-195 Pilot Line Gas Pressure Regulating Valve, 3.5-7.0" W.C. Outlet Adjustment Range, ¼" N.P.T.
561-643-450 Pilot Line Union, ¼" CC Purchase Locally
511-330-086
511-330-086 Pilot Proving Module Ignition Control Module - With 2 Alarm Terminals
511-330-086
510-350-226 Impulse Relay
511-624-580 Push Button Switch
511-624-581 Lens Cover Push-Button Switch
Light Bulb Push-Button Switch
Purchase Locally
511-842-364 Control Transformer, 120/24 Volt, 75 VA Foot Mounted With Circuit Breaker
Natural Gas Parts
511-044-287
511-044-287 Combination Gas Valve, 1"
511-044-287
511-330-221
511-330-221 N/G PIN Pilot Burner Assembly With Pilot Burner, Orifice, Sensing Lead and Ignition Cable Electronic Pilot Burner, With Orifice, Spark and Sense Connections
511-330-221
Propane Gas Parts
383-300-411 Electronic Pilot Burner With Spark and Sense Connections
383-300-410 Standing Pilot Burner
511-330-245 Thermocouple, 48"
511-330-229 Pilot Switch Box
511-246-340 Manual Shut-Off Pilot Gas Valve, ⅛" N.P.T. X ¼" CC Pilot Shut Off Valve-Standing Pilot Line
511-044-279 Combination Gas Valve, 1"
