Miscellaneous Parts And Kits

Find Distributor in your area Distributor Locator
+ −
WM97+ 155 Miscellaneous Parts And Kits Drawing
Index
Part No.
Chemicals
592-900-029 Antifreeze, Sentinel X500 Antifreeze, Sentinel X500 - ( 1 Gallon)
592-900-006
592-900-006 Antifreeze, Sentinel X500 Antifreeze, Sentinel X500 - ( 5 Gallon)
592-900-006
592-900-002
592-900-002 Corrosion inhibitor, Sentinel X100 Sentinel X100
592-900-002
592-900-005
592-900-005 Sentinel X100 Quick Test Kit Sentinel X100 Quick Test Kit
592-900-005
Boiler Accessories
383-700-200
383-700-200 EVG 155 maintenance kit - igniter, igniter gasket, venturi gasket, cover plate gasket, burner gasket, venturi-gas valve o-ring, refractory, silicone, inhibitor test kit, clips and manuals Includes Igniter, Gaskets-(Igniter, Venturi, and Cover Plate),Venturi-Gas Valve O-ring, Reference Onlyractory, Silicone, Inhibitor Test Kit, and Clips
383-700-200
383-700-118 Wall Mount Kit Supplied With Boiler Includes Wall-Mount Bracket, and Hardware
560-907-722
560-907-722 Condensate trap kit Supplied With Boiler Includes Trap Assembly, and Flexible Line
560-907-722
383-800-102 Adjustable Floor Stand
Condensate Handling Accessories
383-500-631
383-500-631 Condensate neutralizer kit
383-500-631
VentAir Parts and Kits (PVC or Stainless Steel)
383-500-397
383-500-397 3” Kit Weil-McLain Sidewall Vent/Air Cap Termination Kit for PVC Vent and Air Pipes - (Includes Sidewall Vent/Air Termination Cap, Inside and Outside Cover Plates and Mounting Hardware) Openings are for 3" PVC Pipe (Requires Field Installed 3" X 2" Adapter if Using 2" Vent/Air Pipes
383-500-397
382-200-430 Weil-McLain sidewall vent/air cap termination kit for AL29-4C vent pipe and PVC air pipe Includes Sidewall Vent/Air Termination Cap, Inside and Outside Cover Plates and Mounting Hardware) Openings are for 3" SS Vent Pipe and 3" PVC Air Pipe (Requires Field Installed 3" X 2" Adapter if Using 2" Vent/Air Pipes
383-700-171 Sidewall Separate Pipes Vent/Air Termination Kit Includes 2 Cover Plates
383-500-100 Kit for 3” or 4” PVC vent and air pipes Sidewall Separate Pipes Vent/Air termination Kit (Includes 2 Cover Plates) - For 3" PVC Vent and Air Pipes
383-700-172 Kit for 3" AL29-4C SS vent pipe and PVC air pipe Sidewall Separate Pipes Vent/Air termination Kit (Includes 2 Cover Plates) - For 3" AL29-4C SS Vent Pipe and 3" PVC Pipe
383-700-167
383-700-167 PVC Concentric Vent Kit Horizontal or Vertical - Kit For 2" PVC Vent/Air Pipes
383-700-167
383-500-350
383-500-350 Kit for 3” PVC vent and air pipes PVC Concentric Vent Kit - Horizontal or Vertical - Kit For 3" PVC Vent/Air Pipes
383-500-350
560-907-728 Bird Screen For 2" PVC Vent/Air Pipes
383-500-105 Bird screens For 3” PVC vent and air pipes
383-700-235 Termination Restrictor Kit Includes Intake Washer, PVC Restrictor, and Instructions
Vent/Air Parts and Kits (Polypropylene Pipe)
M&G Simpson-Duravent PolyPro Sidewall Concentric Vent/Air Kit - For 2" Polypropylene Pipe Available From M&G Simpson-Duravent. Part number: 24PPS-HK - (Color White)
M&G Simpson-Duravent PolyPro Sidewall Concentric Vent/Air Kit - For 3" Polypropylene Pipe Available From M&G Simpson-Duravent. Part number: 35PPS-HK - (Color White)
M&G Simpson-Duravent PolyPro Vertical Concentric Vent/Air Kit - For 2" Polypropylene Pipe Available From M&G Simpson-Duravent. Part number: 24PPS-VK - (Color - Black) or Terra Cotta - (Add -TC Suffix)
M&G Simpson-Duravent PolyPro Vertical Concentric Vent/Air Kit - For 3" Polypropylene Pipe Available From M&G Simpson-Duravent. Part number: 35PPS-VK - (Color - Black) or Terra Cotta - (Add -TC Suffix)
M&G Simpson-Duravent PolyPro SIDEWALL Separate Vent/Air Pipe Kit - For 2" Polypropylene Pipe Available From M&G Simpson-Duravent. Part number: 2PPS-HTP
M&G Simpson-Duravent PolyPro SIDEWALL Separate Vent/Air Pipe Kit - For 3" Polypropylene Pipe Available From M&G Simpson-Duravent. Part number: 3PPS-HTP
Vent/Air Parts and Kits (Polypropylene Pipe)
Centrotherm INNOFLUE Sidewall Concentric Vent/Air Kit - 3" Polypropylene Pipe Available From Centrotherm Eco Systems. Part number: ICWT3452
Centrotherm INNOFLUE Sidewall Concentric Vent/Air Kit - 2" Stainless Steel/PP Pipe Available From Centrotherm Eco Systems. Part number: ICWS2413
Centrotherm INNOFLUE Sidewall Concentric Vent/Air Kit - 3" Stainless Steel/PP Pipe Available From Centrotherm Eco Systems. Part number: ICWS3513
Centrotherm INNOFLUE Vertical Concentric Vent/Air Kit - 2" Polypropylene Pipe Available From Centrotherm Eco Systems. Part number: ICRT2439
Centrotherm INNOFLUE Vertical Concentric Vent/Air Kit - 3" Polypropylene Pipe Available From Centrotherm Eco Systems. Part number: ICRT3539
